PT. Bumi Teknik Utama - Mesin Las Listrik GMAW / MIG MAG - Compact https://www.bumi.info/product-category/welding-machine/mesin-las-listrik-gmaw-mig-mag-compact-2/ Professional Industrial Equipments Thu, 04 Aug 2022 11:00:09 +0000 en-US hourly 1 https://wordpress.org/?v=6.7.5 https://www.bumi.info/wp-content/uploads/2021/01/cropped-B-LOGO-RED-32x32.png PT. Bumi Teknik Utama - Mesin Las Listrik GMAW / MIG MAG - Compact https://www.bumi.info/product-category/welding-machine/mesin-las-listrik-gmaw-mig-mag-compact-2/ 32 32 Mesin Las CO Mig Mag CC/CV Inverter Compact Xi 300 https://www.bumi.info/product/mesin-las-mig-mag-cc-cv-inverter-compact-xi-300/ Tue, 06 Aug 2019 19:07:18 +0000 https://www.bumiteknik.com/?post_type=product&p=31953

[button title="Unduh Katalog (369 KB)" link="/wp-content/uploads/2020/11/Mig-Mag-Inverter-CC-CV-Xi-300-NEW-1.pdf" target="_blank" align="" icon="icon-download" icon_position="left" color="#d6d6d6" font_color="#ed0b0b" size="1" full_width="" class="" download="Mig Mag Inverter CC CV - Xi 300" onclick=""]



Bagikan ke : [sharethis-inline-buttons]

The post Mesin Las CO Mig Mag CC/CV Inverter Compact Xi 300 appeared first on PT. Bumi Teknik Utama.

]]>
bumi teknik utama 00021a
bumi teknik utama 00021

Penggunaan Utama

● Perabotan
● Perbaikan bodi mobil
● Karoseri
● Pengelasan di tempat
● Pembuatan bodi kendaraan.
● Produsen ringan

Keunggulan

● Teknologi CC / CV baru untuk kualitas dan hasil pengelasan yang lebih baik dan mudah digunakan.
● Siklus kerja tinggi, cocok untuk pekerjaan pengelasan ringan hingga menengah.
● Tampilan digital arus dan tegangan pengelasan untuk penyesuaian yang mudah.
● Berbagai proses dalam waktu bersamaan untuk proses pengelasan MMA dan MIG MAG.
● Direkomendasikan untuk pengelasan “produsen bodi kendaraan” dan pengelasan pada lembaran tipis.
● Cocok untuk pengelasan aluminium dengan tebal dari 0,8 – 1,0 mm.

Spesifikasi
Rentang pengelasan60 - 300 A
Tegangan beban17 - 29 V
Tegangan sirkuit terbuka51 V
Welding current at 80 % duty cycle300 A
Welding current at 100 % duty cycle268 A
Input power11.0 KVA
Input current17.0 A
Input phase3 Phase
Tegangan utama, Toleransi380 V, ± 15 %
Frekuensi50 / 60 Hz
Weldable steel wire0.8 - 1.2 mm
Weldable aluminum wire0.8 - 1.2 mm
Power factor0.93
Index protectionIP 23
Insulation classF
Jenis pendinginF
Dimensi (P x L x T)650 x 320 x 580 mm
Berat tanpa aksesori36 Kg

Mig Mag Inverter Package

Item CodeItem Name
101.15.002.1Xi 300 - Mig Mag Inverter Package
Standard Alternative
101.15.002Mig Mag Inverter CC CV - Xi 300
201.23.003CO2 Heater 220V Gas Regulator
201.23.004CO2 Fin Type Gas Regulator
201.23.002CO2 Gas Regulator
201.23.001 Argon Gas Regulator
201.23.005 CO2 Yellow Gas Regulator
250.02.003Mig Torch - Pro Mig 24 at 3 m
250.02.004Mig Torch - Pro Mig 24 at 4 m
250.02.005Mig Torch - Pro Mig 24 at 5 m
250.02.001Mig Torch - Pro Mig 15 at 3 m
250.02.002Mig Torch - Pro Mig 15 at 4 m
Optional Accessories
201.37.001 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm -
Ø 0.8 / 1.0 mm ( V )
201.37.002 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm -
Ø 1.0 / 1.2 mm ( V )
201.37.003 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm -
Ø 0.8 / 1.0 mm ( U )
201.37.004Feed Roll for Xi 300 - 42.3 x 16 x 20 mm -
Ø 1.0 / 1.2 mm ( U )
201.37.005Feed Roll for Xi 300 - 42.3 x 16 x 20 mm -
Ø 1.0 / 1.2 mm ( Knurled )
General Accessories
201.22.009Welding Helmet - Solarmatic Blue
201.22.010Welding Helmet - Solarmatic Red
201.22.011Welding Helmet - Solarmatic Green
208.18.002Torch Holder - MIG

Mig Mag Optional Accessories Package for Alu

Item CodeItem Name
101.15.002.2Xi 300 - Mig Mag Package for Alu
+ Plug to Ground Size 50 mm2 at 3 m - 1 set
+ Gas Hose 8 mm at 2 m - 1 set
+ Hose Clamp 10 mm - 2 pcs
Standard Alternative
101.15.002Mig Mag Inverter CC CV - Xi 300
201.37.004 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm
Ø 1.0 / 1.2 mm ( U )
201.37.003Feed Roll for Xi 300 - 42.3 x 16 x 20 mm
Ø 0.8 / 1.0 mm ( U )
250.02.003Mig Torch - Pro Mig 24 at 3 m
250.02.004Mig Torch - Pro Mig 24 at 4 m
250.02.005Mig Torch - Pro Mig 24 at 5 m
250.02.001Mig Torch - Pro Mig 15 at 3 m
250.02.002Mig Torch - Pro Mig 15 at 4 m
203.12.007 Red Teflon Liner 5 m + Copper Liner
Aluminum Ø 1.0 - 1.2 mm
203.12.006 Blue Teflon Liner 5 m + Copper Liner
Aluminum Ø 0.8 - 0.9 mm
203.12.008 Yellow Teflon Liner 5 m + Copper Liner
Aluminum Ø 1.2 - 1.6 mm
Optional Accessories
201.37.001 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm
Ø 0.8 / 1.0 mm ( V )
201.37.002 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm
Ø 1.0 / 1.2 mm ( V )
201.37.003 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm
Ø 0.8 / 1.0 mm ( U )
201.37.004 Feed Roll for Xi 300 - 42.3 x 16 x 20 mm
Ø 1.0 / 1.2 mm ( U )
General Accessories
201.22.009Welding Helmet - Solarmatic Blue
201.22.010Welding Helmet - Solarmatic Red
201.22.011Welding Helmet - Solarmatic Green
208.18.002Torch Holder - MIG

MMA Optional Accessories

Optional Accessories
208.04.007Plug to Ground Clamp 600 A, 50 mm2 at 5 m
208.03.005Plug to Electrode Holder 400 A, 50 mm2 at 5 m
General Accessories
201.22.009Welding Helmet - Solarmatic Blue
201.22.010Welding Helmet - Solarmatic Red
201.22.011Welding Helmet - Solarmatic Green


Mesin Sejenis

Mesin Las CO Mig Mag Inverter Basic Compact Omega² 300


Consumable Terkait

Kawat Las Flux Cored Wire
E71T-1, Ø 1.2 mm

Anti Spatter
Spray Distac Weld

Anti Spatter Spray Ceramstak

Anti Spatter Pasta Welding

The post Mesin Las CO Mig Mag CC/CV Inverter Compact Xi 300 appeared first on PT. Bumi Teknik Utama.

]]> Mesin Las CO Mig Mag Inverter Basic Compact Omega² 300 https://www.bumi.info/product/mesin-las-mig-mag-inverter-basic-compact-omega%c2%b2-300/ Tue, 06 Aug 2019 03:20:02 +0000 https://www.bumiteknik.com/?post_type=product&p=31948

[button title="Unduh Katalog (147 KB)" link="/wp-content/uploads/2020/11/Mig-Mag-Inverter-Basic-Compact-Omega-300-with-Basic-Panel-NEW.pdf" target="_blank" align="" icon="icon-download" icon_position="left" color="#d6d6d6" font_color="#ed0b0b" size="1" full_width="" class="" download="Mig Mag Inverter Basic - Compact Omega 300 with Basic Panel" onclick=""]



Bagikan ke : [sharethis-inline-buttons]

The post Mesin Las CO Mig Mag Inverter Basic Compact Omega² 300 appeared first on PT. Bumi Teknik Utama.

]]>
bumi teknik utama 00024a
bumi teknik utama 00024b

Penggunaan Utama

● Otomotif dan Karoseri
● Perbaikan dan pemeliharaan
● Perbaikan bodi kendaraan
● Outfitting pada galangan kapal & lepas pantai
● Produksi lembaran yang tipis

Keunggulan

● Siklus pemakaian dan keluaran tinggi untuk pemakaian heavy duty.
● Ditargetkan untuk industry manual dan manufaktur.
● Empat sistem wire feeder gulung untuk pengumpanan yang aman, dan juga untuk kabel lunak.
● Selang gas yang aman dari difusi untuk mencegas kontaminasi gas pelindung
● Hemat energi, ramah lingkungan, masa pakai lebih lama.
● Intelligent Gas Control IGC®, fitur bersifat pilihan yang menyebabkan penghematan gas hingga 50%, lebih hemat biaya.
● Polaritas terbalik untuk pengelasan dengan kawat inner shield (tanpa gas).

Spesifikasi
Rentang pengelasan15 - 300 A
Welding current at 60 % - 40°C195 A
Welding current at 100 % - 40°C175 A
Tegangan sirkuit terbuka52 V
Wire feed speed18 m/min
Input phase3 Phase
Tegangan utama, Toleransi400 V, ±15 %
Frekuensi50 / 60 Hz
Rated power at max. current9.1 KVA
Rated power at 100 %5.3 KVA
Weldable Fe, Ss wire0.8 - 1.2 mm
Weldable cored wire1.2 mm
Weldable Al0.9 - 1.2 mm
Weldable CuSi0.8 - 1.0 mm
kabel koneksi / fuse delayed10 A
Efisiensi0.88
Power factor0.93
Index protectionIP 23
Dimensi (P x L x T)640 x 250 x 550 mm
Berat26 kg

Mig Mag Package

Item CodeItem Name
135.03.001.1 Omega² 300 with Basic Panel -
Mig Mag Inverter Standard Package
+ Omega² basic panel
+ Kit MWF 1.0 V blue
Standard Accessories
135.03.001Mig Mag Inverter - Basic - Compact
Omega2 300 with Basic Panel
235.03.003 Plug to Ground Clamp 600 A, 50 mm2 at 3 m
Standard Alternative
250.02.003Mig Torch - Pro Mig 24 at 3 m
250.02.004Mig Torch - Pro Mig 24 at 4 m
250.02.005Mig Torch - Pro Mig 24 at 5 m
250.02.006Mig Torch - Pro Mig 36 at 3 m
250.02.007Mig Torch - Pro Mig 36 at 4 m
250.02.008Mig Torch - Pro Mig 36 at 5 m
201.23.002CO2 Gas Regulator
201.23.003CO2 Heater 220V Gas Regulator
201.23.004CO2 Fin Type Gas Regulator
Optional Accessories
235.01.004Software IGC - Intelligent Gas Control
235.13.003Trolley
General Accessories
201.22.009Welding Helmet - Solarmatic Blue
201.22.010Welding Helmet - Solarmatic Red
201.22.011Welding Helmet - Solarmatic Green
208.18.002Torch Holder - MIG

Mig Mag Optional Accessories Package for Alu

Item CodeItem Name
135.03.001.2Omega² 300 with Basic Panel
Mig Mag Inverter Standard Package for Alu.
+ Omega² basic panel - 1 Set
+ Kit MWF 1.0 V blue - 1 Set
Standard Accessories
135.03.001Mig Mag Inverter - Basic - Compact
Omega2 300 with Basic Panel
201.23.001Argon Gas Regulator
235.03.003Plug to Ground Clamp 600 A, 50 mm2 at 3 m
Standard Alternative
203.03.001Mig Torch - Ergoplus 24 at 3 m long
203.03.002Mig Torch - Ergoplus 24 at 4 m long
203.03.003Mig Torch - Ergoplus 24 at 5 m long
203.04.001Mig Torch - Ergoplus 36 at 3 m long
203.04.002Mig Torch - Ergoplus 36 at 4 m long
203.04.003Mig Torch - Ergoplus 36 at 5 m long
Optional Accessories
203.12.006Blue Teflon Liner 5m + Copper Liner
Aluminum Ø 0.8 - 0.9 mm
203.12.007Red Teflon Liner 5m + Copper Liner
Aluminum Ø 1.0 - 1.2 mm
235.01.004Software IGC - Intelligent Gas Control
235.13.003Trolley
General Accessories
201.22.009Welding Helmet - Solarmatic Blue
201.22.010Welding Helmet - Solarmatic Red
201.22.011Welding Helmet - Solarmatic Green
208.18.002Torch Holder - MIG

Mesin Sejenis

Mesin Las CO Mig Mag CC/CV Inverter Compact Xi 300

Consumable Terkait

Kawat Las Flux Cored Wire
E71T-1, Ø 1.2 mm

Anti Spatter
Spray Distac Weld

Anti Spatter Spray Ceramstak

Anti Spatter Pasta Welding

The post Mesin Las CO Mig Mag Inverter Basic Compact Omega² 300 appeared first on PT. Bumi Teknik Utama.

]]>
