Fungsi Utama
● Galangan kapal
● Struktur baja
● Industri kimia dan pengolahan
Keunggulan
● Traktor Digitalisasi dapat digunakan untuk berbagai jenis pengelasan kawat seperti kawat filamen & flux cored wire, dan dapat menghemat hingga 10 set data pengelasan sehingga menghemat waktu. Feeding kawat maupun kecepatan gerak traktor stabil, sehingga menghasilkan pengelasan yang sangat baik.
● Kendali tampilan digital, desain, dan penggunaan yang mudah.
● Arc start yang akurat.
● Pengumpan kawat pengarah ganda dengan konfigurasi pelurusan guna menyediakan feeding kawat yang stabil, sentralisasi yang baik, daya tarik yang sangat baik dan daya feeding kawat yang sangat kuat. Performa pengelasan yang sudah banyak disempurnakan.
● Cocok untuk mesin Kobewel – inverter CC/CV – S 1000i.
● Kuat, kokoh dan kaku, terutama di tempat yang paling anda butuhkan.
| Spesifikasi | |
| Tegangan input | DC 110 V ( supplied by Power Source ) |
| Arus pengelasan | 1000 A |
| Diameter kawat | 2 - 6 mm |
| Jenis kawat | Copper - Coated Solid Steel |
| Kecepatan kawat | 0.3 ~ 3 m/min |
| Feeding mode | Automatic |
| Kecepatan pengelasan | 0.2 ~ 1.5 m/min |
| Tinggi torch yang dapat disesuaikan | 70 mm |
| Tinggi traktor yang dapat disesuaikan | 100 mm |
| Adjustable longitudinal distance of tractor head around cross beam | ±30 mm |
| Rotate-able angle of tractor head around cross beam | ≥ ±90° |
| Adjustable longitudinal distance of tractor head | 100 mm |
| Torch inclination | 45° |
| Tractor head inclination | ±45° |
| Kapasitas kawat spool | 25 Kg |
| Flux container volume | 6 l |
| Berat | 54 Kg |
| Item Code | Item Name |
| 101.18.002 | SAW Machine - Tractor 1000 |
| + Power Cable for SAW 70 mm2 at 15 m, 2 set | |
| + Control Cable at 15 m, 1 set | |
| + Feedroll diameter 3.2, 4 & 5 mm | |
| + Contact Tip diameter 3.2, 4 & 5 mm | |
| + Wrench 14 / 17 mm | |
| + Socket Wrench 14 mm | |
| + Hex. Key 8 mm | |
| + Rail Track at 1 m | |
| Optional Accessories | |
| 205.06.001 | SAW Tractor - Contact Tip - M14 Ø 2.0 mm |
| 205.06.002 | SAW Tractor - Contact Tip - M14 Ø 2.4 mm |
| 205.06.003 | SAW Tractor - Contact Tip - M14 Ø 3.2 mm |
| 205.06.004 | SAW Tractor - Contact Tip - M14 Ø 4.0 mm |
| 205.06.005 | SAW Tractor - Contact Tip - M14 Ø 5.0 mm |
| 205.05.001 | SAW Tractor - Feed Roll - Steel Ø 2.0 mm |
| 205.05.002 | SAW Tractor - Feed Roll - Steel Ø 2.4 mm |
| 205.05.003 | SAW Tractor - Feed Roll - Steel Ø 3.2 mm |
| 205.05.004 | SAW Tractor - Feed Roll - Steel Ø 4.0 mm |
| 205.05.005 | SAW Tractor - Feed Roll - Steel Ø 5.0 mm |
| 208.03.001 | Plug to Electrode Holder 600 A, 70 mm2 at 5 m |
| 208.03.002 | Plug to Electrode Holder 600 A, 70 mm2 at 10 m |
| 208.03.003 | Plug to Electrode Holder 600 A, 70 mm2 at 5 m |
| 208.03.005 | Plug to Electrode Holder 400 A, 50 mm2 at 5 m |
| 208.03.006 | Plug to Electrode Holder 400 A, 50 mm2 at 10 m |
| 208.03.007 | Plug to Electrode Holder 400 A, 50 mm2 at 20 m |
| 208.03.008 | Plug to Electrode Holder 400 A, 50 mm2 at 25 m |
| 2018.04.004 | Plug to Ground Clamp 600 A, 70 mm2 at 5 m |
| 2018.04.005 | Plug to Ground Clamp 600 A, 70 mm2 at 10 m |
| 2018.04.006 | Plug to Ground Clamp 600 A, 70 mm2 at 15 m |
| 2018.04.007 | Plug to Ground Clamp 600 A, 50 mm2 at 5 m |
| 2018.04.008 | Plug to Ground Clamp 600 A, 50 mm2 at 10 m |
