Keunggulan Produk
● Tembaga yang kuat, untuk menciptakan kinerja yang lebih baik untuk pekerjaan kontruksi di lokasi kerja.
● Kontrol Valve yang mudah dan cepat untuk gas shielding.
● Pegangan bergaris untuk pengelasan tanpa kelelahan.
● Kabel las sangat fleksibel dengan tingkat isolasi tinggi.
● Memakai komponen yang kompatibel dengan standar internasional.
| Spesifikasi | |
| Jenis Pendinginan | Udara |
| Aliran gas | 7 - 15 l/min |
| Duty Cycle 60 % DC | 150 A |
| Duty Cycle 60 % AC | 135 A |
| Elektroda tungsten Ø | 1.6 - 3.2 mm |
| Item Code | Item Name |
| 208.17.006 | Tig Torch - Air Cooled - WP 17 V-25-2 at 8 m |
| 208.17.012 | Tig Torch - Air Cooled - WP 17 V-25-2 at 8 m - Flexible |
| Pos | Item Code | Item Name | MoQ |
| 1 | 203.17.001 | Alumina Nozzle Short No. 5 (10N49) - TIG 17 - 26 - 18 | 10 Pcs |
| 203.17.002 | Alumina Nozzle Short No. 6 (10N48) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.17.003 | Alumina Nozzle Short No. 7 (10N47) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.17.004 | Alumina Nozzle Short No. 8 (10N46) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.17.005 | Alumina Nozzle Short No. 10 (10N45) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.17.006 | Alumina Nozzle Short No. 12 (10N44) - TIG 17 - 26 - 18 | 10 Pcs | |
| 2 | 203.18.001 | Alumina Nozzle Long No. 5 (10N49L) - TIG 17 - 26 - 18 | 10 Pcs |
| 203.18.002 | Alumina Nozzle Long No. 6 (10N48L) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.18.003 | Alumina Nozzle Long No. 7 (10N47L) - TIG 17 - 26 - 18 | 10 Pcs | |
| 3 | 203.22.001 | Collet Body Ø 1.6 mm (10N31) - TIG 17 - 26 - 18 | 3 Pcs |
| 203.22.002 | Collet Body Ø 2.4 mm (10N32) - TIG 17 - 26 - 18 | 3 Pcs | |
| 203.22.003 | Collet Body Ø 3.2 mm (10N28) - TIG 17 - 26 - 18 | 3 Pcs | |
| 4 | 203.19.001 | Alumina Nozzle Short Gas Lens No. 4 (54N18) - TIG 17 - 26 - 18 | 10 Pcs |
| 203.19.002 | Alumina Nozzle Short Gas Lens No. 5 (54N17) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.19.003 | Alumina Nozzle Short Gas Lens No. 6 (54N16) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.19.004 | Alumina Nozzle Short Gas Lens No. 7 (54N15) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.19.005 | Alumina Nozzle Short Gas Lens No. 8 (54N14) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.19.006 | Alumina Nozzle Short Gas Lens No. 12 (54N19) - TIG 17 - 26 - 18 | 10 Pcs |
| Pos | Item Code | Item Name | MoQ |
| 5 | 203.20.001 | Alumina Nozzle Long Gas Lens No. 5 (54N17L) - TIG 17 - 26 - 18 | 10 Pcs |
| 203.20.002 | Alumina Nozzle Long Gas Lens No. 6 (54N16L) - TIG 17 - 26 - 18 | 10 Pcs | |
| 203.20.003 | Alumina Nozzle Long Gas Lens No. 7 (54N15L) - TIG 17 - 26 - 18 | 10 Pcs | |
| 6 | 203.23.001 | Collet Body Gas Lens Ø 1.6 mm (45V25) - TIG 17 - 26 - 18 | 3 Pcs |
| 203.23.002 | Collet Body Gas Lens Ø 2.4 mm (45V26) - TIG 17 - 26 - 18 | 3 Pcs | |
| 203.23.003 | Collet Body Gas Lens Ø 3.2 mm (45V27) - TIG 17 - 26 - 18 | 3 Pcs | |
| 7 | 203.23.005 | Collet Body Gas Lens Insulator (54N01) - TIG 17 - 26 - 18 | 3 Pcs |
| 8 | 203.32.003 | Torch Head WP 17V | 1 Pc |
| 203.32.004 | Torch Head Flexible WP 17 FV | 1 Pc | |
| 9 | 203.21.001 | Collet Ø 1.6 mm (10N23) - TIG 17 - 26 - 18 | 5 Pcs |
| 203.21.002 | Collet Ø 2.4 mm (10N24) - TIG 17 - 26 - 18 | 5 Pcs | |
| 203.21.003 | Collet Ø 3.2 mm (10N25) - TIG 17 - 26 - 18 | 5 Pcs | |
| 10 | 203.24.001 | Back Cap Long (57Y02) - TIG 17 - 26 - 18 | 3 Pcs |
| 203.24.002 | Back Cap Short (57Y04) - TIG 17 - 26 - 18 | 3 Pcs |
