Penggunaan Utama
● Galangan kapal
● Struktur baja
● Industri kimia dan pengolahan
Keunggulan
● Traktor Digitalisasi dapat digunakan untuk berbagai jenis pengelasan kawat seperti kawat filamen & flux cored wire, dan dapat menghemat 10 set data pengelasan, sehingga menghemat waktu. Feeding kawat maupun kecepatan gerak traktor yang stabil, sehingga menghasilkan pengelasan yang sangat baik.
● Cocok untuk mesin Weldking – Power Source – Master 1000.
● Kuat, kokoh dan kaku, terutama di tempat yang paling Anda butuhkan.
| Spesifikasi | |
| Tegangan input | AC 110 V ( supplied by Power Source ) |
| Arus pengelasan | 1.000 A |
| Diameter kawat | 2 - 5 mm |
| Jenis kawat | Copper - Coated Solid Steel |
| Kecepatan kawat | 0.3 ~ 3 m/min |
| Feeding mode | Automatic |
| Kecepatan pengelasan | 0.2 ~ 1.5 m/min |
| Tinggi torch yang bisa disesuaikan | 70 mm |
| Tinggi kepala traktor yang dapat disesuaikan | 80 mm |
| Adjustable longitudinal distance of tractor head around cross beam | ±30 mm |
| Rotate-able angle of tractor head around cross beam | ≥ ±90° |
| Adjustable longitudinal distance of tractor head | 100 mm |
| Torch inclination | 45° |
| Tractor head inclination | ±45° |
| Kapasitas kawat spool | 25 Kg |
| Flux container volume | 6 l |
| Berat | 55 Kg |
| Item Code | Item Name |
| 105.03.002 | SAW Machine - X 1000 Tractor |
| + SAW Tractor - X 1000 - 1 unit | |
| + Control Cable 6 pin, at 15 m - 1 set | |
| + Power Cable 70 mm at 15 m - 2 Set | |
| + Rail Track at 1 m - 1 pc | |
| + Feed Roll, dia 3.2 mm - 2 pcs | |
| + Feed Roll, dia 4.0 - 5.0 mm - 2 pcs | |
| + Contact Tip M12, dia 3.2 - 1 pc | |
| + Contact Tip M12, dia 4.0 - 1 pc | |
| + Contact Tip M12, dia 5.0 - 1 pc | |
| + Wrench 14 / 17 mm - 1 pc | |
| + Socket Wrench 14 mm - 1 pc | |
| + Hex. Key 8 mm - 1 pc | |
| Optional Accessories | |
| 205.06.001 | SAW Tractor - Contact Tip - M14 Ø 2.0 mm |
| 205.06.002 | SAW Tractor - Contact Tip - M14 Ø 2.4 mm |
| 205.06.003 | SAW Tractor - Contact Tip - M14 Ø 3.2 mm |
| 205.06.004 | SAW Tractor - Contact Tip - M14 Ø 4.0 mm |
| 205.05.001 | SAW Tractor - Feed Roll - Steel Ø 2.0 mm |
| 205.05.002 | SAW Tractor - Feed Roll - Steel Ø 2.4 mm |
| 205.05.003 | SAW Tractor - Feed Roll - Steel Ø 3.2 mm |
| 205.05.004 | SAW Tractor - Feed Roll - Steel Ø 4.0 mm |
| 205.05.005 | SAW Tractor - Feed Roll - Steel Ø 5.0 mm |
| 208.03.001 | Plug to Electrode Holder 600 A, 70 mm2 at 5 m |
| 208.03.002 | Plug to Electrode Holder 600 A, 70 mm2 at 10 m |
| 208.03.003 | Plug to Electrode Holder 600 A, 70 mm2 at 5 m |
| 208.03.005 | Plug to Electrode Holder 400 A, 50 mm2 at 5 m |
| 208.03.006 | Plug to Electrode Holder 400 A, 50 mm2 at 10 m |
| 208.03.007 | Plug to Electrode Holder 400 A, 50 mm2 at 20 m |
| 208.03.008 | Plug to Electrode Holder 400 A, 50 mm2 at 25 m |
| 2018.04.004 | Plug to Ground Clamp 600 A, 70 mm2 at 5 m |
| 2018.04.005 | Plug to Ground Clamp 600 A, 70 mm2 at 10 m |
| 2018.04.006 | Plug to Ground Clamp 600 A, 70 mm2 at 15 m |
| 2018.04.007 | Plug to Ground Clamp 600 A, 50 mm2 at 5 m |
| 2018.04.008 | Plug to Ground Clamp 600 A, 50 mm2 at 10 m |
